24 port Gigabit Ethernet Unmanaged PoE Switch
What is a PoE switch?
POE technology (Power over Ethernet), Ethernet power supply
technology, while also providing DC power supply technology for
some IP-based terminals, such as IP phones, wireless access AP,
network cameras, etc., DC receiving devices called powered devices.
Key Features of Gigabit POE switch
- Support for 24 Gigabit POE ports, + 2 Gigabit SFP optical ports
- Support for IEEE802.3, IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z
- Compatible with IEEE802.3at (30W) and IEEE802.3af(15.4w)
- Ethernet ports support 10 / 100 / 1000M adaptive and POE features
- Support for port automatic flip (Auto MDI/MDIX)
- Exchange mechanism using storage and forwarding
- All ports support line-speed switching
- Zero configuration feature, automatically supplied to adaptive
equipment
- Panel indicators monitor operating status and help with fault
analysis
- Support for the 1-8-port QOS priority
- Three-gear one-key intelligent code dialing switch, supporting
VLAN, Normal, Extend three modes
Specification of Unmanaged network switch
| I/O interface |
| Power supply input | AC100-240V/50-60Hz |
| Ethernet Network | 24* 10 / 100 / 1000Mbps PoE ports 2* Gigabit SFP ports |
| Performance |
| Exchange capacity | 52Gbps |
| Package forwarding rate | 38.68Mpps |
| Package Cache | 4Mbit |
| MAC Address Table | 8K |
| Giant frame | 9.6Kbytes |
| Forward mode | Storage forwarding |
| Standard |
| Network protocol | IEEE 802.3: Ethernet Media Access Control (MAC) protocol IEEE 802.3i:10BASE-T Ethernet IEEE 802.3u:100BASE-TX Fast Ethernet IEEE 802.3ab:1000BASE-T Gigabit Ethernet IEEE 802.3z:1000BASE-X Gigabit Ethernet (Optical Fiber) IEEE 802.3x: Flow Control |
| PoE Standard | IEEE802.3af(15.4W) IEEE802.3at (30W) |
Network media
| 10Base-T: Cat3, 4, 5 Class or above UTP/STP (≤ 100m) 100Base-TX: Cat5 Class or above UTP/STP (≤ 100m) 1000Base-TX: Cat5 Class or above UTP/STP (≤ 100m) Multimode optical fiber: 50/125,62.5/125,100 / 140um Single-mode optical fiber: 8/125,8.7/125,9 / 125,10 / 125um |
| Certification |
| Safety Certification | CE, FCC, RoHS |
| Environmental Standards |
| Working environment | Operating temperature: -10~50 °C Storage temperature: -40~70 °C Working humidity: 10%~90%, no condensation Storage humidity: 5%~95%, no condensation |
| Functional indication |
| Indicator lamp | PWR(Power indication), 1000M(chain street lamp), ACT (data lamp) |
| Status | PWR: Normally lit Equipment powered on / Unlit Equipment Unpowered 1000M: Bright Gigabit / not Gigabit or Link ACT: always bright without data transmission / shiny data
transmission / no link |
| Dial-Up Code Definition | Default:1-24 port standard exchange, free communication for all
ports VLAN:1-24 ports are isolated from each other and communicate with
two optical ports Extend:17-24 port 10M mode, link extended to 250 m |
| Physical specifications |
| Structural dimensions | Product Size: 440 * 204 * 44mm Package Dimensions: 500 * 290 * 85mm Product net Weight: 2.82KG Product gross weight: 3.38KG |
| Boacking Information | Outer box dimensions: 520 * 445 * 310mm Quantity of quantity: 5 PCS Boacking weight: 17.5KG |
| Supply voltage | Input voltage: AC100-240V/50-60Hz Power supply power: 52V/5.76A |
| power | Product power: maximum 15W POE power: maximum 280W |
| Boacking List | Switch: 1, manual: 1, certificate: 1, power cord: 1,1 pair of
hanging ears |
Application of 24 port POE switch
- Urban optical fiber broadband network: telecommunications, cable
TV, network system integration, according to network operators
- Broadband special network: suitable for finance, government, oil,
electricity, public security, education and other industries
